Yamaha Raptor 250 YFM250R – Blue

Yamaha Raptor 250 YFM250R – Blue

Engine

249cc single-cylinder

4-stroke

Air-cooled

SOHC, 2 valves

Bore × stroke: 74 × 58 mm

Compression ratio: 9.5:1

Mikuni 29mm carburetor

Electric start

CDI ignition

Wet-sump lubrication

Transmission & drivetrain

5-speed manual transmission

Manual wet multi-plate clutch

Chain final drive

2WD / rear-wheel drive

Sealed O-ring chain

Suspension

Front: independent double wishbone

Front travel: approximately 7.5 in / 190 mm

Rear: swingarm with single shock

Rear travel: approximately 7.9 in / 200 mm

Adjustable rear shock preload

Brakes

Front: dual hydraulic disc

Rear: hydraulic disc

No ABS

Wheels & tires

Front: 20 × 7-10

Rear: 19 × 10-9

Aluminum wheels on later models

Dimensions

Length: 64.0 in / 1,625 mm

Width: 42.1 in / ~1,070 mm

Height: 40.9 in / 1,040 mm

Wheelbase: 43.7 in / 1,110 mm

Seat height: 28.7 in / 730 mm

Ground clearance: 3.9 in / 100 mm

Wet weight: approximately 331 lb / 150 kg

Fuel capacity: approximately 2.4 gal / 9.1 L
